Model | Hikon RPTS 90 | Hikon RPTS 100 | Hikon RPTS 110 | Hikon RPTS 120 | Hikon RPTS 130 | Hikon RPTS 150 |
Screw Dia (mm) | 90 | 100 | 110 | 120 | 130 | 150 |
Screw Barrel Design | Vented (30:1) | Vented (30:1) | Vented (30:1) | Vented (30:1) | Vented (30:1) | Vented (30:1) |
Output (kg/hr) | 100-150 | 150-175 | 175-200 | 200-250 | 300-350 | 450-500 |
Main Drive (KW) | 18 | 22 | 30 | 45 | 55 | 75 |
Connected Load (KW) | 40 | 50 | 61 | 92 | 122 | 174 |
Space Required | 30'x7'x10' | 34'x7'x10 | 35'x7'x10' | 36'x7'x10 | 37''x8'x12' | 40'x8'x13' |
Sailent Features :-
Model | Hikon C 100 | Hikon C 120 | Hikon C 150 |
Screw Dia (mm) | 100 | 120 | 150 |
Output (kg/hr) | 150-175 | 200-250 | 450-500 |
Main Drive (KW) | 37 | 55 | 88 |
Connected Load (KW) | 111 | 181 | 343 |
Space Required | 25’x15’x10’ | 30’x15’x12’ | 35’x17’x14’ |
Model | Hikon ACE 90 | Hikon ACE 100 | Hikon ACE 120 | Hikon ACE 130 | Hikon ACE 150 |
Screw Dia (mm) | 90 | 100 | 120 | 130 | 150 |
Screw Barrel Design | Vented 33:1/ 35:1 | Vented 33:1/ 35:1 | Vented 33:1/ 35:1 | Vented 33:1/ 35:1 | Vented 33:1/ 35:1 |
Output (kg/hr) | 150-200 | 200-250 | 300-350 | 400-500 | 500-650 |
Main Drive (KW) | 30 | 45 | 55 | 75 | 90 |
Connected Load (KW) | 57 | 80 | 116 | 155 | 207 |
Space Required | 32’x7’x10’ | 34’x7’x10’ | 37’x7’x12’ | 40’x8’x12’ | 45’x8’x13’ |
